Now turbocharged with HDMI output!

Got HDMI? HDMI Output, Auto Focus and 30fps display make the smallest details sharp and crisp - with AVer's 300AFHD Document Camera. This is THE mechanical arm document camera that established AVer's high quality reputation and transformed the learning environment for students and teachers nationwide.
  • 5

    Mega Pixel
  • 30

    FPS
  • 16x

    Digital Zoom
sensor

Full 1080p with 5MP Sensor

With the 300AFHD document camera's full 1080p HDMI output, you are now able to connect your document camera to HDMI displays and HDMI capable projectors, allowing you to see the HD image quality you were meant to see.

auto focus

Quick Auto-Focus & 16x zoom

The 300AFHD document camera's 5MP, 16x zoom and one-touch auto focus combine to provide unsurpassed image quality with stunning detail in the shortest amount of time.

LED

Embedded LED light module

Usually when the projector is on, the lights are off. However, since the 300AFHD document camera is connected to a projector, it has a built-in LED light in the camera head to illuminate and display any object under the camera with ease.

Broadneck Elementary School
The AVer Document Camera has been the best teaching tool I have ever used. I have no regrets about getting the document camera instead of an interactive white board. The document camera has so many more functions and uses than I ever imagined.

Broadneck Elementary School | Read Case Studies

Specifications

Sensor1/3" CMOS Pixel Count5 megapixels
Zooming16X Digital Zoom Shooting AreaMax. 13.66" x 10.28" (337mm x 261mm)


Sensor1/3" CMOSPixel Count5 megapixelsFrame Rate30 fps (max.)
White BalanceAuto / ManualExposureAuto / ManualImage ModeSharp / Graphics / Motion / Microscope
EffectColor / B/W / Negative / Mirror / Rotate / FreezeRGB Output1920x1080, 1280x720, 1280x1024, 1280x800, 1600x1200, 1024x768HDMI Output1920x1080, 1280x720
Optics
FocusAuto / ManualShooting AreaMax. 13.66" x 10.28" (337mm x 261mm)Zooming16X Digital Zoom
Function
Image EffectColor / B&W / Negative / Mirror / Reverse / FreezeWhite balance / exposureAuto / ManualPicture-in-pictureYes
Presentation ToolsSpotlight (Yes), Visor (Yes)Capture Mode Single / ContinuousRemote ControlYes
Image Storage240 Frames (XGA); 80 Frames (5M Pixel)Onboard AV RecordingYes, SD/SDHC/USBOnboard AnnotationYes, works with any HID device (eg. USB Mouse)
Compatibility
Operating SystemsWindows 7 (32/64 bit),
Windows 8 (32/64 bit),
Windows 10 (32/64 bit),
Mac OS X 10.9 or above (Intel based),
Chrome OS 29 or above
AVer Software AVer A+ Software Suite (Sphere 2, PowerPoint Plug-in, Flash-Plug-in), Sphere Lite (for Chromebook)Interactive Whiteboard CompatibilityYes with AVerVision Flash Plug-in *certain limitations apply
Power
Power Source DC 12V, 2A, 100-240V, 50-60HzConsumption10.8 Watts (lamp off); 12 Watts (lamp on)
Lighting
Lamp TypeLED light
Dimension
Operating14.68" x 6.85" x 21.34" 373mm x 174mm x 542mm (+/-2mm include rubber foot)Folded 14.45" x 6.85" x 3.89" 367mm x 174mm x 99mm (+/-2mm include rubber foot)Weight4.4 lbs (2kg)
External Storage
Secure Digital (SDHC)1GB ~ 32GB (FAT32)USB Flash Drive2GB ~ 64GB (FAT32)
Optional Accessories, eStore
Microscope AdapterPart number: VISIONNMAAnti-Glare sheetPart number: PANTIGLA1 (A5 size 8.26" x 5.84")Carrying BagPart number: VISIONPCC
Package Contents
300AFHD
3´ USB Cable (Mini Type)
RGB Cable
Power Adapter 12V/2A
Remote Control (including batteries)
Quick Guide
