The future of auto tracking is here!

Create engaging video for streaming, sharing and recording during lectures, demonstrations, video conferences, speeches, and more with the AVer TR530 Professional Auto Tracking and Live Streaming Camera. The TR530 boasts a powerful PTZ camera with 30X optical zoom and a secondary 120° FOV panoramic camera providing users crystal-clear full HD 1080p video resolution without the need of an experienced camera operator. The TR530 supports IP streaming and the ease of integration to other AV tools allow you to create your best productions!

Wide area tracking

Capture every interaction

Track your target everywhere with Wide Area Tracking. Wide Area Tracking provides presenters the flexibility to leave the stage and interact with a crowd or students, all while being continuously tracked even if they become obscured by other people or objects.

Wide area tracking

Stage tracking

Track your target in any environment

Get high quality, hands-free video streaming and recording with Stage Tracking. Fluidly track your target with Effective Zone settings allowing for up to 8 blocking zones to capture strategic professional looking video.

Segment tracking

Never miss a step

Enhance the capturing of content on multiple displays with Segment Tracking. Create 4 Content Zones that allow for immediate recognition and tracking of your target as they move between Content Zones, perfectly capturing the content on display rather than your presenter.

Segment tracking

Compatible software

Enjoy the unprecedented quality and support

AVerCare delivers industry-leading 3 year advance replacement warranty with free RMA shipping and 24 hour turnaround time. We strive to provide industry leading product quality, service and support so you’re always up and running!

AVerCare

Specifications

Front
Front
Back
Back

Camera

Image sensor Effective picture elements Output resolution
1/2.8" 60fps low lux CMOS sensor 2 megapixels Auto, 1080p/60, 1080p/50, 1080i/60, 1080i/50, 1080p/30, 720p/60
Optical zoom Digital zoom Lens focal length
30X 12X f = 4.3mm (Wide) ~ 129mm (Tele)
Iris View of angle Minimum illumination
F = 1.6 (wide) ~ 4.7 (Tele) DFOV = 76° (wide) ~ 5° (Tele) IRE50 0.47 lux (60fps); 0.23 lux (30fps)
Preset number Minimum working distance White balance
10 (IR remote), 255 (RS232) 1.2 meter at Tele-end (30X); 0.1 meter at Wide-end (1X) Auto/Manual (2500 ~ 10000)
Gain Electronic shutter Back light compensation (BLC)
Auto/Manual 1/5 s to 1/32000 s Off/On
Exposure Noise reduction Frequency
Auto/Shutter Priority/IRIS Priority/Manual Off/Low/Medium/High Auto/50Hz/60Hz
S/N Ratio Horizontal resolution
> 50db Center: 800 TV lines; corner: 600 TV lines

Pan tilt parameter

Pan rotation Tilt rotation Pan control speed
-175° (Left) + 175° (Right) -30° (Down) + 90° (Up) 2° ~ 50°/Sec
Tilt control speed Preset speed
2° ~ 50°/Sec Pan 160°/Sec; Tilt 160°/Sec

Panoramic camera (Full view)

Image sensor Effective picture elements Output resolution
1/2.8" 60fps low lux CMOS sensor 2 megapixels Auto, 1080p/60, 1080p/30, 720p/60
Lens focal length White balance Exposure
2.12mm Auto Auto
FOV
DFOV = 120°, HFOV = 110°, VFOV = 74.5°

Interface/Streaming/Protocol

Output interface Video output capability Remote control
3G-SDI*2, HDMI*1, IP (RJ45) Up to 1080P/60 RS232 (via optional DB9 to DIN6 adapter), IP (RJ45)
Baud rate Network interface Network video compress format
115200/9600/4800/2400 bps 10/100/1000 base-T, support Wake-on-LAN H.264
Network protocol IP video streaming Control protocol
RTSP, RTMP, ONVIF Dual video streaming (PTZ and panoramic view) VISCA/Pelco-D/Pelco-P
Power
DC12V, Power Adapter

System

Remote IR Audio LED
IR sensor PCM, AAC-LC, G.711 Power (Blue-open, Red-close)
Security Infrared remote Power adapter
Kensington slot Receiver on front of camera AC110V-AC220V to DC12V/5A
Consumption Operating temperature Operating humidity
24W (Max.) 0°C ~ +40°C 20% ~ 80%
Storage temperature Storage humidity Dimensions
-20°C ~ +60°C 20% ~ 95% L = 201mm, W = 210mm, H = 176mm
Weight Application Accessory
1.75kg indoor Remote control, 12V/5A power adapter, DIN6 adapter, user manual

Warranty

Camera Accessories
3 years with AVerCare 1 Year

Ordering info

Part number
PAVPTR530

*Specifications subject to change without notice.

Optional accessories
